ETL Data Pipeline with Apache Airflow

ETL Data Pipeline with Apache Airflow : Solution and Documentation

 Introduction

This documentation provides a complete guide to setting up and using an ETL data pipeline with Apache Airflow on a Windows machine using WSL2. The pipeline extracts sample data, transforms it, and loads it, serving as a foundation for real-world ETL workflows.

 Setup Instructions

The following steps replicate and consolidate the setup you’ve completed through Step 5, ensuring clarity for future reference or reinstallation.

Architecture Diagram (Conceptual)

Install WSL2 and Ubuntu

1. Enable WSL2:
   • Open PowerShell as Administrator and run:

wsl –install

1. Set WSL2 as Default:
   • In PowerShell:
     wsl –set-default-version 2

2. Install Ubuntu:
   • Open the Microsoft Store, install “Ubuntu 20.04 LTS.”
   • Launch Ubuntu, set a username (e.g., airflowuser) and password (e.g., yourpassword).
3. Update Ubuntu:
   • In the Ubuntu terminal:
     sudo apt-get update && sudo apt-get upgrade -y

sudo apt-get install -y python3 python3-pip python3-venv

 Install Apache Airflow

1. Create a Project Directory:
   • In Ubuntu:
     mkdir ~/airflow_project && cd ~/airflow_project

2. Set Up a Virtual Environment:
   • Create and activate:
     python3 -m venv airflow_venv

source airflow_venv/bin/activate

3. Install Airflow:
   • Install Airflow 2.7.3 with constraints:
     pip install “apache-airflow==2.10.5” –constraint “https://raw.githubusercontent.com/apache/airflow/constraints-2.10.5/constraints-3.12.txt”

4. Set Airflow Home:
   • Configure and make permanent:
     export AIRFLOW_HOME=~/airflow

echo “export AIRFLOW_HOME=~/airflow” >> ~/.bashrc

source ~/.bashrc

 Initialize Airflow

1. Initialize Database:
   • Run:
     airflow db init

This creates ~/airflow with configuration files and a SQLite database.

2. Create Admin User:
   • Create a user for the web UI:
     airflow users create \

     –username admin \

     –firstname Admin \

     –lastname User \

     –role Admin \

–email admin@example.com
Set a password (e.g., admin123).

3. Start Webserver and Scheduler:
   • In one Ubuntu terminal (with virtual environment activated):
     airflow webserver -p 8080
   • In a new Ubuntu terminal:
     cd ~/airflow_project

source airflow_venv/bin/activate

airflow scheduler

4. Access Airflow UI:
   • Open http://localhost:8080 in a browser.
   • Login with admin and your password (e.g., admin123).

Create the ETL Pipeline

1. Create DAGs Folder:
   • Run:
     mkdir ~/airflow/dags

2. Add the ETL DAG:
   • Create the DAG file:
     nano ~/airflow/dags/simple_etl_pipeline.py
3. Paste the following code:
   • Link: https://drive.google.com/file/d/1cWwh5LROMyWGW2TIA-7O8kdvHfIXKvmd/view?usp=sharing

Save (Ctrl+O, Enter, Ctrl+X)

4. Install Pandas
   • Install the required library:

pip install pandas

5. Verify DAG:
   • In the Airflow UI, check the “DAGs” tab for simple_etl_pipeline.

 Run and Monitor the Pipeline

1. Enable the DAG:
   • In the Airflow UI, toggle the switch for simple_etl_pipeline to “On”.
2. Trigger a Run:
   • Click simple_etl_pipeline, then the “Trigger DAG” button (play icon).
   • Confirm by clicking “Trigger”.
3. Monitor Execution:
   • In the “Graph” view, check task statuses (extract_data, transform_data, load_data).
   • Click a task, select “Log” to view outputs (e.g., “Data loaded successfully: {‘id’: {0: 2, 1: 3}, …}”).

Video: https://www.loom.com/share/8906d615b371463dae0c6283b2f89fe5

Conclusion

This pipeline provides a free, functional ETL workflow using Apache Airflow on Windows via WSL2. The simple_etl_pipeline DAG demonstrates core ETL concepts and can be extended for real-world applications. By following this documentation, you can set up, run, monitor, and customize the pipeline to meet specific data processing needs.
